Available Standard, Grade and Size
| Standard | ASTM B265, ASTM F67, ASTM F136, AMS 4902, AMS 4911 | |
| Grade | Gr1, Gr2, Gr4, Gr5, Gr7, Gr9, Gr12, Gr23 | |
| Size (mm) | Cold Rolled | THK (0.3-4.75) x W (500-1200) x L (1000-3000) |
| Hot Rolled | THK (4.75-80 ) x W (500-2300) x L (1000-8000) | |
Medical Titanium Plate Specifications
YD provide medical grade titanium to meet the growing demand for titanium implants such as titanium bone structure supports, titanium prosthetics, titanium tooth implants.
| Medical titanium plate | ||||
| No. | Grade | Size (mm) | State | Standard |
| 1 | Gr2,Gr3 | 3 x 11 x (500~1000) | bright | ASTM F67 |
| 2 | Gr2,Gr3 | 3.5 x 12 x (500~1000) | bright | ASTM F67 |
| 3 | Gr2,Gr3 | 4 x 14 x (500~1000) | bright | ASTM F67 |
| 4 | Gr5 | THK 3~60 | bright | ASTM F136 |
Heat Exchanger Titanium Plate Specifications
One of the widest and most current uses of titanium sheet today is for its use in titanium heat exchangers. YD provides the highest quality titanium sheet to meet all requirements and application.
| Titanium sheet for plate heat exchanger | |||||
| Grade | Size (mm) | State | Standard | ||
| Thickness | Width | Length | |||
| Gr1, Gr7 | 0.5~0.8 | 200~500 | 500~2000 | M | ASTM B265 |
| 0.9~1.0 | 200~500 | 500~2000 | M | ASTM B265 | |
| 0.5~0.8 | 500~800 | 800~2000 | M | ASTM B265 | |
